9.9 Top Hook Parts
Figure
No.
Part Name
Parts
Per
Hoist
100L 100S
1
Top Hook Complete Assembly
1
ER2IS1011
2
Top Suspension Plate A Assembly
1
ER2IS5011
3
Top Suspension Plate B Assembly
1
ER2IS5012
4 Suspender Shaft B
4
E6S013100
5
Bottom Hook Assembly
1
ER2IS2121
6 Bottom
Hook 1
ER2IS9121
7 Thrust
Bearing 1
ES022100
8 Bearing Cover 1
E6S023100
9 Hook Nut
1
ES024100
10 Bottom
Yoke
1
E6S030100
11
Safety Latch Assembly
1
C2BA1501071
12 Stopper Screw A
1
J1TB01110016
13 Stopper Screw B
1
J1TB01110008
14 Bottom
Stay
Bolt
4
E6S038075
15
Bottom Idle Sheave Assembly
1
ER2HS5052
16 Thrust
Needle
Bearing 2 ER1HS9182
17 Shaft
Stopper A
3
ER1IS9056
18
Top Shaft B
1
E6S057100
20 Guide
Roller 4
E6S062075
21 Bottom
Collar 4
E6S065075
22 Nut
8
9093445
23 Spring Washer 8
9012717
24 Socket
Bolt
6
9091271
25 Spring Washer 6
9012711
26
Connection Yoke Assembly
2
ER2IS5005
27
Connection Yoke Assembly
1
ER2IL5155
28 Yoke
Bolt
1 ER1ES9032
29 Slotted
Nut
1 ES088020L
30 Split
Pin
1 9009436
31 Chain
Pin
1 ES041050
32 Slotted
Nut
1 M2049030
33 Split
Pin
1 9009424
34 Chain
Holder 1
ER1IL9171
35 Chain
Pin
1 E6S041075
36 Snap
Ring 1
9047221
37 Balance
Weight Assembly
1
7021002
