9.3 Chain Parts
*Quantities in “( )” are for dual-body hoists.
Figure
No.
Part Name
Parts
Per
Hoist
080S 100L 100S 150S 200S
1
Chain Guide A
1 (2)
ER2FS9331
2
Chain Guide B
1 (2)
ER2FS9332
3
Socket Bolt
4 (8)
9091274
4
Spring Lock Washer
4 (8)
9012711
5
Machine Screw With Spring Washer
4 (8)
E6F151003
6 Guide
Roller
1
(2)
ER1EM9333
7
Roller Pin
1 (2)
ER2FS9334
8
Limit Lever
1 (2)
ER2FS9337
9
Limit Lever Pin
1 (2)
ER2FS9338
10
Limit Lever Spring
1 (2)
ER2CS9357
21
End Suspender Kit
1 (2)
ENDS2F2
22
Socket Bolt
1 (2)
90912140
23
Lever Nut
1 (2)
ES066075
