Page 43
43
9.8 Top Suspension Plate Parts
Figure
No.
Part Name
Parts
Per
Hoist
150S 200S
1
Top Suspension Plate Assembly
1
ER2JS1003
ER2KS1003
2
Connection Yoke Assembly
2
ER2IS5005
3 Connection Yoke A
2
ER2IS9005
4 Connection Yoke B
2
ER2IS9006
5 Connection Yoke Pin
4
ER2HS9016
6
Top Suspension Plate A Assembly
1
ER2JS5003
ER2KS5003
9
Top Suspension Plate B Assembly
1
ER2JS5004
ER2KS5004
12
Top Stay Bolt
6 (7)
E6S007075
13 Suspension
Shaft
4
E6S008075
14
Top Idle Sheave Assembly
2 (3)
ER2HS5051
15 Thrust
Needle
Bearing 4
(6) ER1HS9182
16
Top Shaft
2 (3)
E6S053075
17 Shaft
Stopper A
4 (5)
ER1HS9056
18 Guide
Roller 6
(8)
E6S062075
19 Nut
12(14)
9093445
20 Spring Washer 12
(14)
9012717
21
Socket Bolt
8 (10)
9091271
22 Spring Washer 8
(10)
9012711
*Quantities in “( )” are for 20 ton hoists.
