Page 41
41
9.8 Top Suspension Plate Parts
Figure
No.
Part Name
Parts
Per
Hoist
080S 100L 100S
1
Top Suspension Plate Assembly
1
ER2HS1003
ER2IS1003
2
Top Suspension Plate A Assembly
1
ER2HS5003
ER2IS5003
5
Top Suspension Plate B Assembly
1
ER2HS5004
ER2IS5004
8
Top Stay Bolt
3 (4)
E6S007075
9
Suspension Shaft
2 (4)
E6S008075
10
Top Idle Sheave Assembly
1
ER2HS5051
11 Thrust
Needle
Bearing
2
ER1HS9182
12 Top
Shaft
1
E6S053075
13
Shaft Stopper A
2 (3)
ER1HS9056
14 Guide
Roller
4
E6S062075
15 Nut
6
(8)
9093445
16 Spring
Washer
6
(8)
9012717
17
Socket Bolt
4 (6)
9091271
18 Spring
Washer
4
(6)
9012711
19
Stopper Shaft
1
E6SE075S9010
Stopper Shaft (300)
1
E7SE075S9019
20 Split
Pin
2
9009448
21 Chain
Holder
1
ER1IL9017
22 Chain
Pin
1
E6S041075
23 Snap
Ring
1
9047221
24
Connection Yoke Assembly
1
ER2HS5005
ER2IS5005
(2 Required)
*Quantities in “( )” are for 10 ton hoists.
