Model OFE/OFG/OEA/OGA-341, 342
2-23. AUTOLIFT PC BOARD 1. Remove electrical power supplied to unit.
REPLACEMENT
(if applicable)
Autolift PC Board To avoid electrical shock or property damage, move the
power switch to OFF and disconnect main circuit
breaker, or unplug cord at wall receptacle.
2.
Remove control panel
3.
Disconnect connectors from PC board.
4. Using 5/16” nut-driver or wrench, remove the 4 nuts securing
Figure 2-77 the autolift PC board to the panel and remove PC board from
panel.
5.
Install new panel in reverse order.
2-24. AUTOLIFT
1. Remove electrical power supplied to unit.
ACTUATOR (MOTOR)
REPLACEMENT
(if applicable)
To avoid electrical shock or property damage, move the
power switch to OFF and disconnect main circuit
breaker, or unplug cord at wall receptacle.
2.
Drain shortening from frypot.
Figure 2-78 3. Remove basket and knock pin from basket hanger. Figure 2-78.
4. Remove rear cover. Figure 2-79.
Figure 2-79
2-28
106
