Henny Penny 342 - Manual (Page 27)

Model OFE/OFG/OEA/OGA-341, 342
2-21. FILTER PUMP AND 7. Remove left side panel.
MOTOR REMOVAL
(Continued)
8. Using 9/16” socket or wrenches, remove the bolts and nuts
securing the motor to the bracket and pull pump, motor, and
piping from unit. Figure 2-74.
Figure
2-74
2-22. AUTOLIFT 1. Remove electrical power supplied to unit.
TRANSFORMER
REPLACEMENT
(if applicable)
To avoid electrical shock or property damage, move the
power switch to OFF and disconnect main circuit
breaker, or unplug cord at wall receptacle.
2.
Remove control panel.
3. Label and remove wires from transformer. Figure 2-75.
Figure 2-75
4. Using 3/8” nut-driver or wrench, remove nuts securing
transformer to panel and remove transformer from panel.
Figure 2-76.
5. Install new transformer in reverse order.
Figure 2-76
1003
2-27
