2.2.2 Connecting an Amplifier Using Analog Audio
Connect an external amplifier of speakers to the line out port to provide
better sound quality. Refer to the following illustration.
R
L
SUBWOOFER
IN
Amplifier and speakers
Audio cable
Cables and connectors are color-coded (red, white).
