Havis-Shields 1996-2008 Crown Victoria Driver and Passenger - Trunk Side Mounts C-TSM-CV-P User Manual
Install instructions c-tsm-cv-d and c-tsm-cv-p, Always

1
C-TSM-CV-P_INST_4-08
INSTALL INSTRUCTIONS
C-TSM-CV-D and C-TSM-CV-P
1996-2008 CROWN VICTORIA
DRIVER and PASSENGER - TRUNK SIDE MOUNTS
• Drill with 1/8” and 3/16” drill bits
• Open End Wrench - 3/8”
• Phillips Screwdriver
TOOLS REQUIRED:
QTY: DESCRIPTION:
PART
#:
3
10/32
X
1/2”
Machine
Screw
GSM33118
3
10/32
Keps
Nut
GSM30028
3
#10 x 3/4” Sheet Metal Screw
GSM33195
HARDWARE:
Always!
• Read all instructions before installing any Havis-Shields Equipment Corp products.
• Check for obstructions (Wire, brake lines, fuel tank, etc.) before drilling any holes!
• Use hardware provided with install kit
• For product support: visit the Install Instructions Section of our website at
http://havis.com/Installation/Installation.html, email [email protected] or call 1-800-524-9900.
LINE DRAWING:
h
0.
Passenger Side shown
# C-TSM-CV-P
