WELL INFORMATION
WELL DEPTH: 12”
WELL L TO R: 48”
WELL FRONT TO BACK: 22.5”
GALLONS TO OVERFLOW: 62
SLOPE OF DRAIN: .375” per ft.
Special Notes: This unit complies with ANSI Z124.1, ICC/ ANSI A117.1, UPC, HUD,ASTM F462, ASTM E84, ADA, ABA, SBCCI, NAHB.
Warranty: Gelcoat models have a 3 year limited warranty. Acrylic models have a 5 year limited warranty. Pumps, parts, and accessories 1 year limited warranty.
For further details please refer to the complete warranty section.
Due to the nature of the materials, dimensions may vary +/- 1/2”.
DRAWING REQUEST MUST BE MADE FOR PACKAGE 2 DRAWING AND BULIT TO ORDER UNITS.
702A rev. 09/25/07
A 6032 TS I
OD: 60” x 33” x 84”
2.5” ABOVE FLOOR ROUGH
WEIGHT: 225
LOAD FACTOR: 1.26
HANDED BY: VALVE WALL L/R
A 6032 TS IBS
PHOTOGRAPH AT LEFT
ILLUSTRATES PACKAGE ONE
(HANDED BY VALVE WALL RIGHT)
Premium Cast Acrylic
Five Year Warranty
Primary Applications:
• Healthcare
• College Dormitory
• Hospitality
• Schools
ADA Tub Showers ONE-PIECE DOMED ACRYLIC
702A- NO MODIFICATIONS TO PACKAGES. FOR BUILT TO ORDER UNIT, SELECT BASE UNIT AND ACCESSORIES.
PKG ONE-ADA/ANSI/TAS: A 6032 TS IBS List: $ 3016
18" Apron SHIM
Handed by Valve Wall L/R WHITE PREMIUM CAST ACRYLIC
Factory Installed Accessories (VALVE/SHOWER KIT NOT INCLUDED IN PKG1)
S-BAR 24” X 1.5” SMOOTH SS
S-BAR 24" X 1.5" SMOOTH SS
S-BAR 24" X 1.5" SMOOTH SS
S-BAR 24" X 1.5" SMOOTH SS
S-BAR 24" X 1.5" SMOOTH SS
ROD 1" OD 20 GAUGE SS GROMMET STYLE
SEAT 27" X 15" WOODGRAIN PHENOLIC FOLD UP
FOR ADA/ANSI/TAS COMPLIANCE: SEAT AT HEAD END OF TUB SHALL BE PROVIDED AND PERMANENTLY AND
SECURELY MOUNTED, INSTALLED ACCESSORIES MUST INCLUDE: 24” VERTICAL GRAB BAR ON VALVE WALL, 24"
GRAB BAR ON VALVE WALL, TWO 24" GRAB BARS ON BACK WALL, 12" MIN. GRAB BAR ON HEAD WALL,
PRESSURE BALANCING MIXING VALVE, HAND HELD SHOWER WITH SLIDE BAR, VACUUM BREAKER AND 60"
HOSE. UNIT AND ACCESSORIES INSTALLED PER ADA/ANSI/TAS AND PRAXIS INSTALLATION AND WARRANTY
GUIDELINES.
B U I L D T O O R D E R B A S E P L U S A C C E S S O R I E S
BASE UNIT 1:
A 6032 TS I List: $1824
18" Apron SHIM
Handed by Valve Wall L/R
Reinforced for Standard Accessories
BASE UNIT OPTIONAL ACCESSORIES List:
FINISHES
STANDARD FINISH- PREMIUM CAST ACRYLIC: WHITE, BONE, BISCUIT $0
GRAB BARS
S-BAR 24" X 1.5" SMOOTH SS $128
S-BAR 24" X 1.25" SMOOTH WHITE $154
STANDARD SEATS
(ATTACHED OR REMOVABLE)
SEAT 27" X 15" WOODGRAIN PHENOLIC FOLD UP (NOT AVAILABLE WITH 48” S-BAR) $481
SEAT 28" X 15" WHITE TRI FOLD REMOVABLE $434
FACTORY MODIFICATIONS
MOD WHIRLPOOL SYSTEM WITH 3/4 HORSE POWER AND 4 JETS $562
MOD VALVE DRILLING - SPECIFY HOLE SIZE $56
MOD INSTALL STANDARD SYMMONS VALVE PACKAGE $633
MOD INSTALL HANS GROHE THERMOSTATIC VALVE PACKAGE (XLT) $501
MOD INSTALL POWERS VALVE PACKAGE (XLT) $656
MOD INSTALL 30" SLIDE BAR / HS KIT $411
MOD 1.5" STANDARD ROUGH (17" APRON) $56
CURTAIN RODS
ROD 1" OD 20 GAUGE SS GROMMET STYLE $71
ROD 1" OD 20 GAUGE WHITE GROMMET STYLE $138
ROD 5’x 1" OD 20 GAUGE CHROME CURVED WITH BRACKETS $148
FIELD INSTALLED ACCESSORIES
LOOSE CURTAIN HEAVY DUTY 66" X 72" WHITE VINYL $119
ADDITIONAL ACCESSORIES AND SERVICES MAY BE AVAILABLE UPON REQUEST
Hamilton Bathware/Praxis Companies, LLC.
435 Industrial Road, Savannah • Tennessee 38372 • Customer Service: 800.326.5489 • Fax: 888.246.0466 • www.hamiltonbathware.com
Product Availability
Hamilton Northeast
XLT-EXTENDED LEADTIME
Product Availability
Hamilton Mid-America
XLT-EXTENDED LEADTIME
Product Availability
Hamilton South
STD-STANDARD LEADTIME
Commercial Showers & Tub Showers
60” Acrylic Tub Shower
