Special Notes: This unit complies with ANSI Z124.2, ASTM F462, ASTM E84, UPC, SBCCI, NAHB.
Warranty: Gelcoat models have a 3 year limited warranty. Acrylic models have a 5 year limited warranty. Pumps, parts, and accessories 1 year
limited warranty. For further details please refer to the complete warranty section.
Due to the nature of the materials, dimensions may vary +/- 1/2”.
DRAWING REQUEST MUST BE MADE FOR PACKAGE 2 DRAWING AND BULIT TO ORDER UNITS.
719
H 4836 I
OD: 48” x 35.5” x 84”
WEIGHT: 200
LOAD FACTOR: 1.06
HANDED BY: VALVE WALL L/R
ADA / ANSI
Roll-In Showers
ONE-PIECE DOMED ACRYLIC
H 4836 IBS
PHOTOGRAPH AT LEFT
ILLUSTRATES PACKAGE ONE
(HANDED BY VALVE WALL RIGHT)
Premium Cast Acrylic
Five Year Warranty
Primary Applications:
• Public Buildings
• Healthcare
• College Dormitory
• Hospitality
• Schools
Hamilton Bathware/Praxis Companies, LLC.
435 Industrial Road, Savannah • Tennessee 38372 • Customer Service: 800.326.5489 • Fax: 888.246.0466 • www.hamiltonbathware.com
Product Availability
Hamilton Northeast
XLT-EXTENDED LEADTIME
Product Availability
Hamilton Mid-America
XLT-EXTENDED LEADTIME
Product Availability
Hamilton South
STD-STANDARD LEADTIME
Commercial Showers & Tub Showers
48” Acrylic Shower
Accessible Showers DOME TOP ACRYLIC
719- NO MODIFICATIONS TO PACKAGES. FOR BUILT TO ORDER UNIT, SELECT BASE UNIT AND ACCESSORIES.
PKG ONE -ACCESSIBLE: H 4836 IBS List: $1986
2" THRESHOLD MUDSET
Handed by Valve Wall L/R WHITE PREMIUM CAST ACRYLIC
Factory Installed Accessories (VALVE/SHOWER KIT NOT INCLUDED IN PKG1)
S-BAR 24" X 1.5" SMOOTH SS
L-BAR 25" X 20" X 1.5" SMOOTH SS RADIUS
SEAT ACRYLIC MOLDED SEAT L/R
ROD 1" OD 20 GAUGE SS GROMMET STYLE
B U I L D T O O R D E R B A S E P L U S A C C E S S O R I E S
BASE UNIT 1:
H 4836 I List: $1604
SPECIFY THRESHOLD HEIGHT MUDSET
Handed by Valve Wall L/R
Reinforced for Standard Accessories
BASE UNIT OPTIONAL ACCESSORIES List:
FINISHES
STANDARD FINISH- PREMIUM CAST ACRYLIC: WHITE, BONE, BISCUIT $0
GRAB BARS
S-BAR 24" X 1.5" SMOOTH SS $117
S-BAR 24" X 1.25" SMOOTH WHITE $154
S-BAR 24” X 1.25” PEENED SS $136
L-BAR 25" X 20" X 1.5" SMOOTH SS RADIUS $195
L-BAR 25" X 20" X 1.25" SMOOTH WHITE RADIUS $298
L-BAR 25" X 20" X 1.25" PEENED SS RADIUS $220
STANDARD SEATS
SEAT ACRYLIC MOLDED SEAT L/R $100
SEAT 28.5" X 21" FRAMELESS WHITE HDPE RAD $723
SEAT 28.5" X 21" FRAMELESS WHITE PADDED RAD $723
SEAT 28.5" X 21" FRAMELESS WOODGRAIN PHENOLIC RAD $723
FACTORY MODIFICATIONS
MOD MODIFIED DRAIN LOCATION-SPECIFY LOCATION $500
MOD VALVE DRILLING - SPECIFY HOLE SIZE $56
MOD .75” THRESHOLD (EASYBASE) $111
MOD 2” THRESHOLD $0
MOD INSTALL 30" SLIDE BAR / HS KIT $411
MOD INSTALL STANDARD SYMMONS VALVE PACKAGE $633
MOD INSTALL HANS GROHE VALVE PACKAGE (XLT) $501
MOD INSTALL POWERS VALVE PACKAGE (XLT) $656
CURTAIN RODS
ROD 1" OD 20 GAUGE SS GROMMET STYLE $71
ROD 1" OD 20 GAUGE WHITE GROMMET STYLE $138
FIELD INSTALLED ACCESSORIES
LOOSE CURTAIN PREMIUM 54" X 72" WHITE NYLON WTD $180
LOOSE CURTAIN HEAVY DUTY 54" X 72" WHITE VINYL WTD $111
ADDITIONAL ACCESSORIES AND SERVICES MAY BE AVAILABLE UPON REQUEST
