WELL INFORMATION
WELL DEPTH: 9.5”
WELL L TO R: 48”
WELL FRONT TO BACK: 18”
GALLONS TO OVERFLOW: 42
SLOPE OF DRAIN: .375” per ft.
Special Notes: This unit complies with ANSI Z124.1, ICC/ ANSI A117.1, UPC, HUD, ASTM F462, ASTM E84, ADA, ABA, SBCCI, NAHB, UFAS.
Warranty: Gelcoat models have a 3 year limited warranty. Acrylic models have a 5 year limited warranty. Pumps, parts, and accessories 1 year limited warranty.
For further details please refer to the complete warranty section.
Due to the nature of the materials, dimensions may vary +/- 1/2”.
DRAWING REQUEST MUST BE MADE FOR PACKAGE 2 DRAWING AND BULIT TO ORDER UNITS.
705A rev. 09/25/07
G 3260 TS I
OD: 60” x 32.375” x 76.75”
4.125” ABOVE FLOOR ROUGH
WEIGHT: 170
LOAD FACTOR: 1.13
HANDED BY: VALVE WALL L/R
G 3260 TS IBS
PHOTOGRAPH AT LEFT
ILLUSTRATES PACKAGE ONE
(HANDED BY VALVE WALL RIGHT)
Sanitary Grade Polyester
Gelcoat
Three Year Warranty
Primary Applications:
• Healthcare
• College Dormitory
• Hospitality
• Schools
• Assisted Living
ADA Tub Showers ONE-PIECE OPEN TOP GELCOAT
705A- NO MODIFICATIONS TO PACKAGES. FOR BUILT TO ORDER UNIT, SELECT BASE UNIT AND ACCESSORIES.
PKG 1-ADA/ANSI/TAS: G 3260 TS IBS List: $1945
18" APRON SHIM
HANDED BY VALVE WALL L/R WHITE POLYESTER GELCOAT FINISH
Factory Installed Accessories (VALVE/SHOWER KIT NOT INCLUDED IN PKG1)
S-BAR 24” X 1.5” SMOOTH SS
S-BAR 24" X 1.5" SMOOTH SS
S-BAR 24" X 1.5" SMOOTH SS
S-BAR 24" X 1.5" SMOOTH SS
S-BAR 24" X 1.5" SMOOTH SS
SEAT 27" X 15" WOODGRAIN PHENOLIC FOLD UP
FOR ADA/ANSI/TAS COMPLIANCE: SEAT AT HEAD END OF TUB SHALL BE PROVIDED AND PERMANENTLY AND
SECURELY MOUNTED, INSTALLED ACCESSORIES MUST INCLUDE: 24” VERTICAL GRAB BAR ON VALVE WALL, 24"
GRAB BAR ON VALVE WALL, TWO 24" GRAB BARS ON BACK WALL, 12" MIN. GRAB BAR ON HEAD WALL,
PRESSURE BALANCING MIXING VALVE, HAND HELD SHOWER WITH SLIDE BAR, VACUUM BREAKER AND 60"
HOSE. THE UNIT AND ACCESSORIES MUST BE INSTALLED PER ADA/ANSI/TAS AND PRAXIS INSTALLATION AND
WARRANTY GUIDELINES.
B U I L D T O O R D E R B A S E P L U S A C C E S S O R I E S
BASE UNIT 1:
G 3260 TS I List: $824
18" APRON SHIM
Handed by Valve Wall L/R
Reinforced for Standard Accessories
BASE UNIT OPTIONAL ACCESSORIES List:
FINISHES
STANDARD FINISH- POLYESTER GELCOAT FINISH: WHITE, BONE, BISCUIT $0
GRAB BARS
S-BAR 24" X 1.5" SMOOTH SS $128
S-BAR 24" X 1.25" SMOOTH WHITE $154
STANDARD SEATS
(ATTACHED OR REMOVABLE)
SEAT 27" X 15" WOODGRAIN PHENOLIC FOLD UP ATTACHED $481
SEAT 28" X 15" WHITE TRI FOLD REMOVABLE $434
FACTORY MODIFICATIONS
MOD WHIRLPOOL SYSTEM WITH 3/4 HORSE POWER AND 4 JETS $562
MOD VALVE DRILLING - SPECIFY HOLE SIZE $56
MOD INSTALL STANDARD SYMMONS VALVE PACKAGE $633
MOD INSTALL HANS GROHE THERMOSTATIC VALVE PACKAGE (XLT) $501
MOD INSTALL POWERS VALVE PACKAGE (XLT) $656
MOD INSTALL 30" SLIDE BAR / HS KIT $411
MOD ARMORSHIELD P3 PROTECTION $149
MOD TUBGUARD P3 PROTECTION 60" TUB SHOWER $86
CURTAIN RODS
ROD CURTAIN ROD U CUP HOLDER PAIR $14
ROD 1" OD 20 GAUGE SS $71
ROD 1" OD 20 GAUGE WHITE $138
FIELD INSTALLED ACCESSORIES
LOOSE CURTAIN HEAVY DUTY 66" X 72" WHITE VINYL $119
LOOSE TUBGUARD P3 PRO FIELD INST - STANDARD 60" TUB SHOWER $89
ADDITIONAL ACCESSORIES AND SERVICES MAY BE AVAILABLE UPON REQUEST
Hamilton Bathware/Praxis Companies, LLC.
435 Industrial Road, Savannah • Tennessee 38372 • Customer Service: 800.326.5489 • Fax: 888.246.0466 • www.hamiltonbathware.com
Product Availability
Hamilton Northeast
STD-STANDARD LEADTIME
Product Availability
Hamilton Mid-America
STD-STANDARD LEADTIME
Product Availability
Hamilton South
NA-NOT AVAILABLE
*SEE UNIT G 6092 TS IBS
Commercial Showers & Tub Showers
60” Gelcoat Tub/Shower
