THIS UNIT FEATURES THE OUTSIDE DIMENSIONS OF 60” OF OVERALL WIDTH. THIS DOES
NOT ALLOW FOR FULL ENCLOSURE OF THE BOLTS THAT ARE USED TO SECURE THE BARS
AND SEAT IN PLACE. THE BOLT AND NUT COMBINATION SHOULD NOT PROTRUDE ANY
MORE THAN 3/4” ON EITHER SIDE. THIS SHOULD NOT CREATE ANY TYPE OF INSTALLATION
PROBLEMS EXCEPT FOR A DRY WALL ENCLOSED FIRE WALL INSTALLATION AREA THAT
WOULD NOT ALLOW FOR ANY VARIATIONS. IN A STANDARD STUD / OPENING INSTALLATION
THE EXTENSION OF THE HARDWARE SHOULD NOT CAUSE ANY TYPE OF PROBLEM.
Special Notes: This unit complies with ANSI Z124.2, ASTM F462, ASTM E84, UPC, SBCCI, NAHB.
Warranty: Gelcoat models have a 3 year limited warranty. Acrylic models have a 5 year limited warranty. Pumps, parts, and accessories 1 year
limited warranty. For further details please refer to the complete warranty section.
Due to the nature of the materials, dimensions may vary +/- 1/2”.
DRAWING REQUEST MUST BE MADE FOR PACKAGE 2 DRAWING AND BULIT TO ORDER UNITS.
715
G 6096 SH 1S
OD: 60” X 35” X 73”
WEIGHT: 180
LOAD FACTOR: 1.26
HANDED BY: SEAT L/R
ADA / ANSI
Roll-In Showers
ONE-PIECE DOMED ACRYLIC
G 6096 SH 1S
PHOTOGRAPH AT LEFT
ILLUSTRATES PACKAGE ONE
(HANDED BY SEAT LEFT)
Sanitary Grade
Polyester Gelcoat
Three Year Warranty
Primary Applications:
• Healthcare
• College Dormitory
• Multi-Family
• Assisted Living
Hamilton Bathware/Praxis Companies, LLC.
435 Industrial Road, Savannah • Tennessee 38372 • Customer Service: 800.326.5489 • Fax: 888.246.0466 • www.hamiltonbathware.com
Product Availability
Hamilton Northeast
STD-STANDARD LEADTIME
Product Availability
Hamilton Mid-America
STD-STANDARD LEADTIME
Product Availability
Hamilton South
STD-STANDARD LEADTIME
Commercial Showers & Tub Showers
60” Gelcoat Shower
Accessible Showers ONE-PIECE GELCOAT
715- NO MODIFICATIONS TO PACKAGES. FOR BUILT TO ORDER UNIT, SELECT BASE UNIT AND ACCESSORIES.
PKG ONE-ACCESSIBLE: G 6096 SH 1S List: $969
4” THRESHOLD WHITE POLYESTER GELCOAT FINISH
Handed by SEAT L/R
Factory Installed Accessories (VALVE/SHOWER KIT NOT INCLUDED IN PKG1)
S-BAR 24" X 1.5" SMOOTH SS
SEAT MOLDED 21" H
B U I L D T O O R D E R B A S E P L U S A C C E S S O R I E S
BASE UNIT 1:
G 6096 SH 1S List: $852
SPECIFY THRESHOLD HEIGHT
Handed by SEAT L/R
Reinforced for Standard Accessories
BASE UNIT OPTIONAL ACCESSORIES List:
FINISHES
STANDARD FINISH- POLYESTER GELCOAT FINISH: WHITE, BONE, BISCUIT $0
GRAB BARS
S-BAR 24" X 1.5" SMOOTH SS $117
S-BAR 24" X 1.25" SMOOTH WHITE $154
S-BAR 24" X 1.25" PEENED SS $136
FACTORY MODIFICATIONS
MOD VALVE DRILLING - SPECIFY HOLE SIZE $56
MOD 4” THRESHOLD $111
MOD ARMORSHIELD P3 PROTECTION $149
MOD INSTALL 30" SLIDE BAR / HS KIT $411
MOD INSTALL STANDARD SYMMONS VALVE PACKAGE $633
MOD INSTALL HANS GROHE VALVE PACKAGE (XLT) $501
MOD INSTALL POWERS VALVE PACKAGE (XLT) $656
MOD TUBGUARD P3 PROTECTION 60" X 36" SH $86
CURTAIN RODS
ROD CURTAIN ROD U CUP HOLDER PAIR $14
ROD 1" OD 20 GAUGE SS $71
ROD 1" OD 20 GAUGE WHITE $138
FIELD INSTALLED ACCESSORIES
LOOSE CURTAIN PREMIUM 66" X 72" WHITE NYLON WTD $180
LOOSE CURTAIN HEAVY DUTY 66" X 72" WHITE VINYL WTD $119
LOOSE TUBGUARD P3 PROTECTION 60" X 36" SH $74
ADDITIONAL ACCESSORIES AND SERVICES MAY BE AVAILABLE UPON REQUEST
