Operating instructions
149 443
81
C 4.74
Operating the implements
Attaching implements
The various implements are attached to the front or rear
power lift*.
There are 2 different fastening categories:
Category I
Pin diameter 22 mm
Category II Pin diameter 28 mm
The vehicle can be adjusted to both categories by adjusting
the pintle hook bars and providing the pintle hooks with or
without reducer sleeves.
DANGER
Only use the following specified devices for
attaching your implement.
Secure the implement against shifting or roll-
ing.
* Option
