Operating instructions
149 443 51
C 4.74
Taking into operation
Adjust the driver’s seat with mechanical suspension
DANGER
Do not adjust the seat while driving. Risk of
accidents!
1 Horizontal adjustment
- Raise the handle (1) and push the seat to the front
or rear.
- Release the handle and allow the seat lock to
engage.
2 Weight adjustment
- Adjust the desired driver’s weight by turning the
weight adjustment lever (2).
- If the adjustment is correct, the position set at the
height adjustment handle (4) is indicated in the
window (3).
3 Height adjustment
- Three different heights can be set with the hand-
wheel (4).
- The weight should be adjusted after each height
adjustment.
NOTE
To prevent damage to your health, the indi-
vidual adjustment should be checked and
adjusted before taking the vehicle into serv-
ice.
1 2
4 3
Bild_C024
