Hearth and Home Technologies 839-1290 - Manual (Page 51)

September 1, 2008 Page 51 Quadra-Fire · Topaz · 7009-113G
Orifice, Pilot, NG, EZ, #62 842-4440
Paint, Touch-up, Matte Black 7000-304
Paint, Touch-up, Porcelain Mahogany 855-1450
Paint, Touch-up, Powder Coat Crème TOUCHUP-CCR
Paint, Touch-up, Powder Coat Linden Green TOUCHUP-CLG
5 Pilot Assembly, NG 842-4940
6 Refractory Assembly BRICK-TOPAZ
Regulator, Conversion, S.I.T., LP 230-1520
Regulator, Conversion, S.I.T., NG 230-1570
Relief Door Assembly 7011-011
12 Side Kit, Matte Black SIDE-TPZ-MBK
12 Side Kit, Porcelain (Must specify color) SIDE-TPZ-POR
Snap Disc Bracket 7009-108
Snap Disc, Ceramic, 125 230-0960
Speed Control 842-0370
21 Switch Bracket 7009-105
19 Switch, Rocker, ON/OFF 230-0730
Thermocouple, 34 in. 200-2950
Thermopile/Generator, Millivolt 842-0250
Top Mount 468-0420
24 Top, Matte Black 468-0010MBK
24 Top, Porcelain See chart below.
24 Top, Powder Coat See chart below.
Topaz Shipping Kit 842-5140
13 Valve Bracket 7009-104
15 Valve, S.I.T, LP 842-0230
15 Valve, S.I.T, NG 842-0240
Wire Harness 7009-114
IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on your dealer's VIP site. When
ordering, supply serial and model numbers to ensure correct service parts.
D.
Service Parts List
(cont’d.)
R
TOPAZ
(NG, LP) Exploded Parts Diagram Beginning Manufacturing Date: 12-8-03
Ending Manufacturing Date:
Item
#
Part Description
Alphabetical Order
Part #
CAST PARTS - INDIVIDUAL PIECES
Add color code to SKU. Example 466-0060MBK
Item
#
Part Description
Alphabetical Order
Part # Color Code
Ash Lip 466-0060 MBK - Matte Black CCR - Powder Coat Cream
Door Assembly, Left 466-5030 PBK - Porcelain Black CLG - Powder Coat Linden Green
Door Assembly, Right 466-5020 PBL - Porcelain Blue CSB - Powder Coat Sienna Bronze
2 Face Assembly, Solitaire 7009-007 PCR - Porcelain Creme CWL - Powder Coat Willow
Face 466-0010 PGR - Porcelain Green
23 Grille, Top Vent 468-0040 PMH - Porcelain Mahogany
24 Top 468-0010 PMB - Porcelain Midnight Blue
