Page 30 September 1, 2008 Quadra-Fire · Topaz · 7009-113G
D. Accessories
Install approved accessories per instructions included with
accessories. Refer to Section 12 for appropriate accesso-
ries.
Shock or fire risk.
Use ONLY optional accessories approved for
this appliance.
• U s i n g n o n - l i s t e d a c c e s s o r i e s v o i d s
warranty.
• Using non-listed accessories may result in a
safety hazard.
• Only Hearth & Home Technologies approved
accessories may be used safely.
WARNING
C. Leg Leveling System
Figure 8.8 Thread Allen bolts through nuts until flush. The
Allen bolts and nuts are included in the component pack inside
the appliance firebox.
Figure 8.9 Slide assembled nuts and bolts into the slots on
the legs with the nuts on the bottom.
Figure 8.10 Use a 5/32 in. 4mm) Allen wrench to adjust legs
up and down to desired level.
Figure 8.6 Install vent pipe adapter with gasket or high-temp
silicone to rear vent opening.
Figure 8.7 Place grille gently into the opening on top of the
appliance.
