September 1, 2008 Page 49 Quadra-Fire · Topaz · 7009-113G
IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on your dealer's VIP site. When
ordering, supply serial and model numbers to ensure correct service parts.
D.
Service Parts List
(cont’d.)
R
TOPAZ
(NG, LP) Exploded Parts Diagram
Beginning Manufacturing Date: 12-8-03
Ending Manufacturing Date:
Item
#
Part Description
Alphabetical Order
Part #
Adapter, DV (4 in.) 200-2470
Adapter, DV (6-5/8 in.) 7000-162
Air Deflector 7011-139
8 Air Shutter Assembly 468-5060
Ash Lip, Matte Black 466-0060MBK
Ash Lip, Porcelain (specify color - see chart on page 50) See chart on page 50
Ash Lip, Powder Coat (specify color - see chart on page 50) See chart on page 50
14 Back Shield, Lower 7009-107
16 Back Shield, Upper 7009-106
Blower Bracket 7010-146
27 Brick Retainer 479-0190
10 Bulkhead 26457
9 Bulkhead Stop 474-0090
4 Burner Assembly BRNR-TOPAZ
Burner Pan, Left Side 7011-128
Burner Pan, Rear 7011-126
Burner Pan, Right Side 7011-127
26 Cast Mounting Bracket, Bottom 7009-102
25 Cast Mounting Bracket, Top 7009-101
Component Pack (Includes ON/OFF Valve; Mineral Wool; Pilot Injector, EZ, LP, 35; Conversion Regulator, S.I.T.,
LP; LP Orifice (.073); Conversion Label; Leveling Assembly; Snap Disc Bracket; Owner’s Manual; Warranty Card;
Touch-up Paint and Fasteners.) MBK: 7009-003
PMH: 7009-016
CCR: 7009-017
CLG: 7009-012
Conversion Kit, LP, EZ 844-9230
Cover Plate 7010-159
Damper Plate 468-0360
Dashboard Label 250-7170
3 Door Assembly 7011-003
Door Assembly, Left, Matte Black 466-5030MBK
Door Assembly, Left, Porcelain (specify color - see chart on page 50) See chart on page 50
Door Assembly, Left, Powder Coat (specify color - see chart on page 50) See chart on page 50
Door Assembly, Right, Matte Black 466-5020MBK
Door Assembly, Right, Porcelain (specify color - see chart on page 50) See chart on page 50
Door Assembly, Right, Powder Coat (specify color - see chart on page 50) See chart on page 50
11 Door Retainer Assembly 7009-008
Elbow, .375 ML Flare x .375 200-0720
Elbow, Brass, 3/8 COMP x 3/8 MPT 17524A
Electrode, S.I.T., EZ, Flush 842-4580
2 Face Assembly, Solitaire, Matte Black 7009-007MBK
2 Face Assembly, Solitaire, Porcelain (specify color - see chart on page 50) See page 50
