Page 50 September 1, 2008 Quadra-Fire · Topaz · 7009-113G
IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on your dealer's VIP site. When
ordering, supply serial and model numbers to ensure correct service parts.
D.
Service Parts List
(cont’d.)
R
TOPAZ
(NG, LP) Exploded Parts Diagram Beginning Manufacturing Date: 12-8-03
Ending Manufacturing Date:
2 Face Assembly, Solitaire, Powder Coat (specify color - see chart on page 50) See chart on page 50
1 Face Assembly, Quartet, Matte Black 844-9380
1 Face Assembly, Quartet, Porcelain (Must specify color - Mahogany or Crème) 844-4120
1 Face Assembly, Quartet, Powder Coat Creme 466-5000CCR
1 Face Assembly, Quartet, Powder Coat Linden Green 466-5000CLG
Face, Matte Black 466-0010
Face, Porcelain (specify color - see chart on page 50) See chart on page 50
Face, Powder Coat (specify color - see chart on page 50) See chart on page 50
Flex Line 3/8 COMP x 30 in. 200-2940
Flex Line 3/8 Flare x 22L 7000-197
Gasket, Cover Plate 7010-160
Gasket, Elbow 460-0610
Glass Assembly 7011-015
22 Grille, Rear Vent, Matte Black 844-9830
22 Grille, Rear Vent, Porcelain Crème 844-9840
22 Grille, Rear Vent, Porcelain Mahogany 844-9860
22 Grille, Rear Vent, Porcelain Midnite Blue 844-9870
22 Grille, Rear Vent, Powder Coat Crème RV-TPZ-CCR
22 Grille, Rear Vent, Powder Coat Linden Green RV-TPZ-CLG
22 Grille, Rear Vent, Powder Coat Sienna Bronze RV-TPZ-CSB
22 Grille, Rear Vent, Powder Coat Willow RV-TPZ-CWL
23 Grille, Top Vent, Matte Black 468-0040MBK
23 Grille, Top Vent, Porcelain See chart on page 50
23 Grille, Top Vent, Powder Coat See chart on page 50
Hinge Assembly 454-5030
Hinge Pin, Gold 844-5750
Hinge Pin, Nickel 433-1590
20 Igniter, Piezo 230-0612
Injector, Pilot, EZ, LP, 35 200-2630
18 Knob, Extension, Valve, HI/LO 842-4020
17 Knob, Extension, Valve, ON/OFF 842-4030
Latch, Draw 229-0640
Leveling Assembly 7000-000
7 Log Set 468-5070
Magnet, Round 7000-140
Mineral Wool 200-2550
ON/OFF Valve 15697A
Orifice, LP, (.073) 24220
Orifice, NG 24691
Item
#
Part Description
Alphabetical Order
Part #
