1 • Installation 22
2. Connect the main cable. The main cable connects the mouse cable
(needed to use the remote control as a mouse) and serial cable
(needed to use the ELP Link II software) to the projector.
a. Connect the small end of the main cable to the projector’s
Mouse/Com 1 port. (Use the Mouse/Com 2 port if you are
connecting a second computer.)
b. Connect the MAC mouse cable to the mouse terminal on the
other end of the main cable.
c. Connect the mouse connector of the MAC mouse cable to the
mouse port on the back of the PowerBook.
main cable
MAC mouse
cable
MAC serial
cable
