Connecting to a Computer 13
2. Connect the main cable. The main cable connects the PS/2 mouse
cable (needed to use the remote control as a mouse) and 9-pin
serial cable (needed to use the ELP Link II software and the Effects
buttons on the remote control) to the projector.
a. Connect the small end of the main cable to the projector’s
Mouse/Com 1 port. (Use the Mouse/Com 2 port if you are
connecting a second computer.)
b. Connect one end of the PS/2 mouse cable included with the
projector to the mouse terminal on the square end of the main
cable.
main cable
9-pin serial
cable
PS/2 mouse
cable
