7 • Technical Specifications 98
Monitor and Computer In 1/2 connector pin assignments
The Monitor and Computer In 1/2 connectors are female video RGB,
15-pin micro-D-style connectors. The pin assignments are:
Input pin Monitor connector signals Computer In 1/2 connector signals
1 Red out / red video Red video
2 Green out / green video Green video
3 Blue out / blue video Blue video
4 Reserved Monitor (ID bit 2)
5 GND GND
6 GND Red video GND
7 GND Green video GND
8 GND Blue video GND
9 Reserved +5 V
10 GND Synchronous GND
11 Reserved Monitor (ID bit 0)
12 Reserved SDA
13 Horizontal sync Horizontal sync
14 Vertical sync Vertical sync
15 Vertical sync Reserved
