61
Effects settings
fig.effect-link2.eps
4
Use the [SCRUB/VALUE] dial to specify the channels to
be linked.
fig.effect-play2.eps
5
In the same way, set the “PLAY” and “REC” fields.
PLAY
fig.effect-rec.eps
REC
fig.effect-para.eps
6
Press the [DISPLAY] button.
The effect parameter screen is shown on the display.
* The effect parameter screen does not appear when 0: No Effect is
selected as the type.
7
Use the [CURSOR] buttons and the [SCRUB/VALUE]
dial to set each effect parameter.
fig.effect-para2.eps
8
If you selected “CH1 CH2 CH3 CH4” or “CH1+2 CH3+4” in
the “Link” field, press the [DISPLAY] button.
The next channel (or pair of channels) will appear in the display.
While setting effect parameters, you can return to the previous screen by pressing the [EXIT]
button
. The effect settings you make are stored until you change them. However, if you change
the effect type (Type), the settings you made are reset to the default values.
9
When finished setting the effect parameters, press the [EXIT] button to return to the Main screen.
Each effect has various parameters that you can adjust to alter the character of the effect. The settings you
make are stored even when the R-4 Pro power is switched off. However, if you change the effect type, these
settings are reset to the default values.
OFF The effect are not applied during playback
ON The effect are applied during playback
OFF The effect are not applied during recording
ON The effect are applied during recording
