Installation and Operation, cont’d

DVS 406 • Installation and Operation

2-12

matches the output rate of the DVS 406’s scaler to the frame rate of input 1. Select
this feature if you will be using motion video sources with a display that is
capable of a variety of refresh rates.

Available Scaler Output Resolutions and Rates

Resolution

50 Hz 56 Hz 60 Hz 75 Hz Lock @ 50/60* True 72/100*

640 x 480

X

X**

X

X

X

800 x 600

X

X**

X

X

X

848 x 480

X

X**

X

X

X

852 x 480

X

X**

X

X

X

1024 x 768

_

X

X**

X

X

X

1280 x 768

_

X**

X

X

1280 x 1024

X

X**

X

X

1360 x 765

X

X**

X

X

X

1365 x 1024

X

X**

X

X

1400 x 1050

X

X**

X

HDTV 480p

X**

X

HDTV 576p

X**

X

HDTV 720p

X**

X

HDTV 1080p

X**

X

HDTV 1080i

X

X**

X

Resolution locked to input #1

* Rate is auto-selected based on input.

** Default refresh rate

The default resolution and rate is 640 x 480 @ 60Hz.

Output Sync (RGB format)

Using either the horizontal Adjust (

)

or vertical Adjust ( ) knob, select the sync

format required by the display: RGBHV, RGsB (sync on green), or RGBS
(composite sync).

Sync Polarity

The display or projector may require a particular combination of horizontal (H)
and vertical (V) sync signal polarities. Select the appropriate combination of
positive or negative H and V sync by rotating either the horizontal Adjust (

)

or

vertical Adjust ( ) knob.

Audio Configuration

The following flowchart provides an overview of the Audio Configuration
submenus and the options for each setting.
