Installation and Operation, cont’d
DVS 406 • Installation and Operation 2-10
Main menus
Input Configuration
The following flowchart provides an overview of the Input Configuration
submenus and the options for each setting.
Extron
DVS 406
Input
Configuration
MENU
NEXT
Input Video Type
#1 RGB Pass Thru
Input Video Type
#2 YUVi #3 Vid
Input Video Type
#4 Vid #5 Vid
NEXT NEXT NEXT
Input 1 video types
• RGB pass-through
(default)
• YUV pass-through Input 2 video types
• RGBp pass-through
• RGBcS
• YUVi (default)
• YUVp Input 3 video
types
• Video (default)
• S-video Input 4 video
types
• Video (default)
• S-video Input 5 video
types
• Video (default)
• S-video
If you press the Menu button while a submenu is active, the next main menu
will become active. For example, the menu will change from the Input
Configuration menu or submenus to the Output Configuration main menu.
To return to the default screens, let the DVS 406 time-out for 10 seconds, or
press the Menu button until the Exit Menu menu appears, then press the Next
button.
Power
on
Extron
DVS 406
Input
Configuration
2 sec.
2 sec.
Input #2
RGB
MENU
MENU
Output
Configuration
MENU
Audio
Configuration
MENU
Memory
Presets
MENU
Advanced
Configuration
MENU NEXT
MENU
Exit
Menu
