S1C6200/6200A CORE CPU MANUAL EPSON 53
3 INSTRUCTION SET
LD r,XH
Load XH into r-register
LD r,XH
r
←
XH
1 1 1 0 1 0 1 0 0 1 r 1 r 0 EA4H to EA7H
V
5
Not affected
Not affected
Not affected
Not affected
Loads the four high-order bits of register X into the r-register.
LD B,XH LD MX,XH
XH register 1010 1010 1010
B register 0010 1010 1010
Memory (MX) 0000 0000 1010
LD r,XL Load XL into r-register
LD r,XL
r
←
XL
1 1 1 0 1 0 1 0 1 0 r
1
r
0
EA8H to EABH
V
5
Not affected
Not affected
Not affected
Not affected
Loads the four low-order bits of register X into the r-register.
LD MY,XL LD A,XL
XL register 0000 0000 0000
A register 1101 1101 0000
Memory (MY) 0001 0000 0000
