JP NZ,s
Jump if not zero
JP NZ,s
PCB
←
NBP, PCP
←
NPP, PCS
←
s 7 to s 0 if Z = 0
0 1 1 1 s 7 s 6 s 5 s 4 s 3 s 2 s 1 s 0 700H to 7FFH
I
5
Not affected
Not affected
Not affected
Not affected
Jumps to the destination address specified by the 8-bit operand when the zero flag
is not set.
JP NZ,10H
PCB 1 1
NBP 1 1
PCP 0000 0000
NPP 0000 0000
PCS 0000 0111 0001 0000
Z flag 0 0
JP s Jump
JP s
PCB
←
NBP, PCP
←
NPP, PCS
←
s
7
to s
0
0 0 0 0 s
7
s
6
s
5
s
4
s
3
s
2
s
1
s
0
000H to 0FFH
I
5
Not affected
Not affected
Not affected
Not affected
Unconditional jump to the destination address specified by the 8-bit operand.
PSET 0AH JP 10H
PCB 0 0 0
NBP 0 0 0
PCP 0000 0000 1010
NPP 0001 1010 1010
PCS 0100 0010 0100 0011 0001 0000
