6. To remove an M.2 solid-state drive, do the following:
a. Loosen the screw that secures the M.2 solid-state drive 1 .
b. Remove the M.2 solid-state drive with the screw holder from the M.2 solid-state drive slot 2 .
c. Remove the screw holder from the M.2 solid-state drive 3 .
Figure 70. Removing the M.2 solid-state drive
7. To install an M.2 solid-state drive, do the following:
a. Align the notch 1 in the screw holder with the corresponding notch 2 in the M.2 solid-state drive.
Insert the screw holder onto the new M.2 solid-state drive as shown.
Figure 71. Inserting the screw holder onto the M.2 solid-state drive
Chapter 7 . Hardware removal and installation 95
