SIMM Upgrade

Optional Installations and Mode Switch Bank Settings

B-7

B.4

SIMM UPGRADE

Memory upgrade is available for the 2H252-25R to expand its DRAM to 32 MB. This section
explains how to locate and add/replace a Single In-line Memory Module (SIMM). For information
on the available SIMM upgrades, call Enterasys Networks for technical support. For details on
getting help, refer to

Section 1.2

.

B.4.1

Locating SIMMs

Figure B-3

shows the two locations of the DRAM SIMM connector.

Figure B-3

SIMM Slot Locations

2504-84

DRAM

FRONT PANEL

TOP VIEW WITHOUT COVER

Primary

Power

Supply

Redundant

Power

Supply
