Connecting an Escient Touch Screen
Two RS-232 serial ports are available on FireBall-MP. You must use COM 1 to control
FireBall-MP from the optional Escient ETP-1000 Touch Screen.
Other touch screen systems may be compatible. Please contact your dealer for more
information.
The RS-232 cable needed to connect FireBall-MP to the Escient ETP-1000 touch screen
is included with the touch screen.
u
Connect one end of this cable to COM 1.
v
Connect the other end of this cable to the RS-232 communication port on the
ETP-1000 touch panel.
See section “To Change Com Port Settings” in Chapter 7 to enable and configure the
touch screen for use.
2
Please consult your Dealer or the
Escient website if you wish to use
a touch screen not specified in this
manual.
