Under submenus 2.1 and 2.2, set the audio, video and program information for each
encoding input.
Enter Video Input to set the video corresponding parameters.
Note: Supports CC for SDI encoding only
Under submenu 2.2, set the audio corresponding parameters.
 Audio format
Under the “Audio” submenu, select the audio format for this encoding input source, these
Thor Broadcast encoders support MPEG-1 Layer II, MPEG-2 AAC, MPEG-4 AAC and AC3.
 Dialog Normal
Set the dialog level of this device
Video
Video format
MPEG-2 H.264 Video Bit rate
12.000Mbps
Low delay
Normal Model1 Model2 Manual CC Switch
EIA608 EIA708 Line21 CC OFF
Resolution
1920 × 1080 50i
Video in Status
Locked
B frame
2 P frame
4
DTS delay
200
Audio
Audio format
MPEG-1 Layer II
Dialog Normal
-31dB
