10 EN
Names of parts
1 3 2
6
5
9
7
8
0
a
b
h
f
g
e
d
i
c
4
1 Mode dial lock .................................P. 24
2 Rear dial* ( o)
........................P. 26 – 29, 60, 76 – 77, 80
3 F dial
(Exposure compensation dial) ........P. 45
4 R (Movie)/H button ........P. 35, 74/P. 84
5 Shutter button .................................P. 25
6 Cable release connector ...........P. 30, 31
7 Front dial* ( r)
........................P. 26 – 29, 60, 76 – 77, 80
8 Mode dial ........................................P. 24
9 Creative dial ....................................P. 38
0 Lens attachment mark ....................P. 15
a z (Preview) button .........................P. 74
b Mount (Remove the body cap before
attaching the lens.)
c Stereo microphone ...........P. 69, 84, 102
d ON/OFF switch ..............................P. 17
e Self-timer lamp/AF illuminator
.............................................P. 56/P. 104
f Speaker
g Strap eyelet.....................................P. 12
h Lens release button ........................P. 15
i Lens lock pin
* In this manual, the
r
and
o
icons represent operations performed using the front dial
and rear dial.
Names of parts
