Operating the Equipment Locally
3.7.17
Setting Up Video Index
Table 3.26 Setting Up Video Index
Step Action
Result
1
Scroll down to Menu 3.10.7
and edit the parameter for
enabling Video Index insertion
(ENABLED or DISABLED).
Press Save.
Edits the parameter for enabling Video Index
pass-through.
3.7.18
Setting Up Monochrome Samples
Table 3.27 Setting Up Monochrome
Step Action
Result
1
Scroll down to Menu 3.10.8
and edit the parameter for
enabling Monochrome
samples insertion (ENABLED
or DISABLED). Press Save.
Edits the parameter for enabling Monochrome
samples.
3.7.19
Setting Up AMOL 1 and 2
Table 3.28 Setting Up AMOL 1 and 2
Step Action
Result
1
Scroll down to Menu 3.10.9
and edit the parameter for
enabling AMOL insertion
(ENABLED or DISABLED).
Press Save.
Edits the parameter for enabling AMOL pass-
through.
3.7.20
Setting Up NTSC Pedestal Insertion
Table 3.29 Setting Up NTSC Pedestal Insertion
Step Action
Result
1
Scroll down to Menu 3.10.10
and edit the parameter for
enabling NTSC Pedestal
insertion (ENABLED or
DISABLED). Press Save.
Edits the parameter for enabling NTSC Pedestal
insertion.
EN/LZT 790 0003/2 R1A
3-21
