Installing the Equipment
In addition, four unbalanced digital audio outputs are available
via separate BNC connectors.
Table 2.5 Analogue/Digital Audio Connectors
AUD 1
Item Specification
Connector type 9-way, D-type, Male
Connector
designations AUDIO 1
AUDIO 2
Pin-outs Pin 1 - Digital audio +
Pin 2 - Ground
Pin 3 - Left +
Pin 4 - Right +
Pin 5 - Ground
Pin 6 - Digital audio -
Pin 7 - Ground
Pin 8 - Left -
Pin 9 - Right -
Nominal output
impedance 50 Ω
Maximum data rate 3.072 Mbps
Analogue Output level +18 dBm nominal clipping level.
Selectable in range 12 to +24 dBm.
Load impedance ≥600 Ω balanced
Table 2.6 Digital (Unbalanced) Audio Connectors
Item Specification
Connector type BNC 75 Ω socket
Connector designation AUD 1, AUD 2, AUD 3 and AUD 4
Pin-outs Centre
Shield Digital Audio output (AES/EBU)
Ground/Chassis
2.7.5 SVGA Output (RGB HV)
The EQUIPMENT is equipped with a SVGA 15-pin D-type
connector for video output monitoring in the standard
configuration.
The SVGA connector shall be set to RGB/HV (SVGA) or
YPrPb under control of the user interface and remote
control interfaces.
