Operating the Equipment Locally
Table 3.13 Setting Aspect Ratio
Step Action Result
1 Scroll to Menu 3.1.9 and edit
the parameter for aspect ratio
(4:3, or 16:9). Press Save. Edits the parameter for the output SD aspect
ratio.
3.7.5 Setting Video Delay
This menu allows the user to vary the output presentation delay.
Note: This will delay both the video and audio presentation.
Table 3.14 Setting Video Delay Mode
Step Action Result
1 Go to Menu 3.1.11 and edit the
option displayed. Press Save Edits the values for either the 4:2:0 or 4:2:2
output delay. This has a maximum value of
199 mS.
3.7.6 Setting Video Output mode
This menu allows the user to edit the analogue HD video output.
Note: This applies to the analogue connector only.
Table 3.15 Setting Video Ddelay Mode
Step Action Result
1 Go to Menu 3.1.12 and edit
the parameter (RGB or
YPbPr) displayed. Press
Save Edits the HD output format
3.7.7 Setting Low Delay Mode – RX1290/SWO/LDELAY
This menu allows the user to set the receiver into low delay mode.
Note: In this mode only MPEG-1 layer II audio (Musicam) audio and 4:2:0 video is
supported.
This will reduce the decoding delay through the RX1290 by up to 320mS, depending
on video mode.
EN/LZT 790 0003/2 R1A 3-16
