Technical Specification
B.5.2 Audio Outputs
Table B.23 Digital (Unbalanced) Audio Connectors
Item Specification
Connector type BNC 75 Ω socket
Connector designation AUD 1, AUD 2, AUD 3 and AUD 4
Pin-outs Centre
Shield Digital Audio output (AES/EBU)
Ground/Chassis
Table B.24 Analogue and Digital Audio Output Connector
Item Specification
Safety status SELV
Connector type 2 x 9-Way D-type
Connector designation AUDIO 1
AUDIO 2
Output level +18 dBm nominal clipping level.
Selectable in range 12 to +24 dBm.
Nominal output
impedance 50 Ω
Load impedance ≥600 Ω
Compressions layers MPEG-2 layer 1 and 2, linear audio and Dolby Digital (AC-3)
Sampling rates 48 kHz
Output formats Analogue, AES3 and Dolby Digital AC-3
B.5.3 Data Outputs
B.5.3.1 RS-232 Asynchronous (Low-speed) Data
Table B.25 RS-232 Asynchronous (Low-speed) Data Connector
Item Specification
Safety status SELV
Connector type 9-Way D-type
Connector designation RS232/RS422 DATA OUT
Data rates (bit/s) 1200; 2400; 4800; 9600; 19 200; 38 400
Standards EIA RS-232C / ITU-T BT. V.24/V.28
Line length < 15 meters
EN/LZT 790 0003/2 R1A B-20
