Technical Specification
B.4.2 LNB Power and Control
The Multi-Format Receiver provides LNB power and control signals through the
active RF input connector. LNB power and controls are enabled through the Satellite
Input Menu, see Annex C, Menus.
The Multi-Format Receiver supports voltage controlled LNBs only. The LNB power
circuit provides automatic protection against short circuits in the LNB or its cable.
When the short circuit has been removed recovery is automatic. Switchable boost of
the LNB voltage to allow for losses in long cables and control of 22 kHz tone
insertion are provided. The LNB power characteristics comply with IEC 1319-1 and
are as per Table B.13.
Table B.13 LNB Power and Control
Parameter Specification
Voltage V (nominal) Receiver
Polarisation 7
Voltage 13
18
Vertical/circular right
Horizontal/circular left
Current 350 mA maximum
LNB control 22 ± 2 kHz tone
Tone amplitude 0.65 ±0.2 Vp-p
Boost voltage 1 V typical
B.4.3 TTV G.703 (DS3 and E3) OTTV G.703 (DS3 and E3) (Option Card)
Table B.14 TTV G.703 Input Specification
Input Specification
Safety status SELV
Connector type BNC, Female
Input impedance 75 Ω
Data rate DS3: 45 Mbps
E3: 34 Mbps
Network Type PDH
Network
Specification CCITT (ITU-T) G.703
Reed-Solomon On/Off, Not available in 188-packet mode
7 Receive Polarisation: As specified in ETS 300 784: Satellite Earth Station and Systems (SES); Television Receive-only (TVRO) earth
stations operating in the 11/12 GHz frequency bands.
EN/LZT 790 0003/2 R1A B-15
