PLANET ICA-3550V - Manual (Page 58)

5 Mega-pixel Outdoor IR PoE IP Camera
ICA-3550V
58
3.8.2 Schedule
After completing the schedule setup, the camera data will be
Schedule
recorded according to the scheduled setup.
Snapshot
After enabling the snapshot function, user can select the
storage position of snapshot file, the interval time of snapshot
and the reserved file name of snapshot.
The interval between two snapshots. Interval
3.8.3 I/O Setting
The ICA-3550V supports 1 input / 1 output. When input is triggered, it can send the video to
some specific mail addresses, transmit the video to remote ftp server, and trigger the relay and
SAMBA.
The GPIO I/O port input activates related action when I/O input
Alarm Input Setting
is triggered.
