FGSW-2620VM / FGSW-2624SF User’s Manual
Object Description
QoS Mode Provide different modes for QoS Configuration, the available options are shown as below:
Disable QoS Priority,
High Empty Then Low,
Highest:secHigh:SecLow:Lowest=8:4:2:1
Highest:secHigh:SecLow:Lowest=15:7:3:1
Highest:secHigh:SecLow:Lowest=15:10:5:1
Default mode is Highest:secHigh:SecLow:Lowest=8:4:2:1
Static Port Ingress
Priority
Allow to assign Ingress priority on each port of the Switch, the available options are OFF and
0-7. Default mode is 0.
802.1p Priority [7-0] Allow assign high and low on each priority, the available options are shown as below:
Lowest, SecLow, SecHigh, Highest.
Save button Press this button for save current QoS configuration of each port on the Switch.
802.1p Priority: Priority classifiers of the Switch forward packet. COS range is from 0 to 7.
Seven is the high class. Zero is the less class. The user may configure the mapping
between COS and Traffic classifiers.
4.5 Security
In Security page, it has five parts of setting
„ 802.1x/Radius,
„ Access control list,
„ Static MAC address,
„ MAC filter
„ IP security.
We will describe the configure detail in following.
