MVC 121 • Remote Control
Remote Control, cont’d
Using the software
To run the software:
1 . Double click the Audio Products Control Program icon in
the Extron Electronics program group.
2 . Click the comm port that is connected to the unit’s remote
connector.
3 . Click OK. The Audio Products Control Program
main window displays the input gain/attenuation
settings for each channel and allows the user to
adjust them. The user can also adjust the volume
setting for the output channel. See “Setting output volume
range limits” in this chapter.
The window contains channel mute, front panel lock out
(executive modes), and unit reset controls.
The front panel lockout feature prevents unauthorized
adjustments to the MVC’s front panel. See Front panel
security lockout (executive mode) in chapter 2.
Setting output volume range limits
The Master output volume control can be configured with
upper and lower range limits to restrict the volume output.
Setting range limits may prevent possible damage to audio
equipment. From the File drop-down menu, select Advanced
Setup, then select Set Limits.
3-10
