Installation

Manual No. DB11-000028-00

2-3

Table 2-1. Jumper Descriptions

Jumper

Description

Default Setting

JP1

N/A

-

JP2

pins 1–2 normal, pins 2–3 blank ROM mode

1-2

JP3

manufacturing diagnostics – do not use

-

JP4

N/A

-

JP5

maintenance – do not use

-

J5

External LED (SCSI LED)

n/a
