Platinum Spot 5R™
©Elation Professional, Los Angeles Ca. 45 www.ElationLighting.com
32-39 Gobo 4
40-47 Gobo 5
48-55 Gobo 6
56-63 Gobo 7
64-71 Gobo 8
72-79 Gobo 9
80-87 Gobo 10
88-95 Gobo 11
96-103 Gobo 12
104-111 Gobo 13
112-119 Gobo 14
120-126 Gobo 1 shake slow to fast
127-133 Gobo 2 shake slow to fast
134-140 Gobo 3 shake slow to fast
141-147 Gobo 4 shake slow to fast
148-154 Gobo 5 shake slow to fast
155-161 Gobo 6 shake slow to fast
162-168 Gobo 7 shake slow to fast
169-175 Gobo 8 shake slow to fast
176-182 Gobo 9 shake slow to fast
183-189 Gobo 10 shake slow to fast
190-196 Gobo 11 shake slow to fast
197-203 Gobo 12 shake slow to fast
204-210 Gobo 13 shake slow to fast
211-217 Gobo 14 shake slow to fast
218-255 Gobo wheel rotation from slow to fast
Fixed gobo indexing Fine
11
0-255 Fixed gobo Fine indexing
3 facet rotating prism, Prism / Gobo macros:
0-31 Open
32-127 Rot. Prism
128-135 Macro 1
136-143 Macro 2
144-151 Macro 3
152-159 Macro 4
160-167 Macro 5
168-175 Macro 6
176-183 Macro 7
184-191 Macro 8
9 7 12
192-199 Macro 9
