Platinum Spot 5R™
©Elation Professional, Los Angeles Ca. 44 www.ElationLighting.com
70-83 Color 5
84-97 Color 6
98-111 Color 7
112-127 Color 8
128-189 Forwards rainbow effect from fast to slow
190-193 No rotation
194-255 Backwards rainbow effect from slow to fast
Color Wheel Fine:
6
0-255 Color Wheel color change to any position (Fine)
Rotating gobos, cont. rotation:
0-9 Open
10-19 Rot. gobo 1
20-29 Rot. gobo 2
30-39 Rot. gobo 3
40-49 Rot. gobo 4
50-59 Rot. gobo 5
60-69 Rot. gobo 6
70-79 Rot. gobo 7
80-89 Rot. gobo 8
90-104 Rot. gobo 1 shake
105-119 Rot. gobo 2 shake
120-134 Rot. gobo 3 shake
135-149 Rot. gobo 4 shake
150-164 Rot. gobo 5 shake
165-179 Rot. gobo 6 shake
180-194 Rot. gobo 7 shake
195-209 Rot. gobo 8 shake
6 4 7
210-255 Rot. gobo wheel cont. rotation slow to fast
Rotating gobo index, rotating gobo rotation:
0-127 Gobo indexing
128-189 Forwards gobo rotation from fast to slow
190-193 No rotation 7 5 8
194-255 Backwards gobo rotation from slow to fast
Rotating gobo indexing Fine
9
0-255 Fine indexing
Fixed Gobos:
0-7 Open/hole
8-15 Gobo 1
16-23 Gobo 2
8 6 10
24-31 Gobo 3
