Platinum Spot 5R™
©Elation Professional, Los Angeles Ca. 33 www.ElationLighting.com
LOCK – This function allows you to lock the keys on the display to prevent menu
tampering. With this function you can activate the automatic keylock function. If this
function is activated, the keys will be automatically locked in 15 seconds from the
last command. In order to deactivate or temporarily deactivate the keylock function,
press the Mode/Esc Button for 3 seconds to regain access to the menu commands.
9.4.4 Temperature C/F – This function changes the temperature the unit will display
from either Celsius or Fahrenheit. Fahrenheit is set as the default measurement.
9.4.5 Initial effect – This function allows a user to create and assign a custom “Home
Position” into the fixture. Adjusting the Pan and Tilt values then locking those values into
the fixture’s internal memory creates the new “Home” position.
9.4.6 Restore Default – This function is used to restore the factory settings of the
device. All settings will be set back to the default values (shaded). Any edited scenes will
be lost.
9.5 Reset Functions: The reset function returns a motor to the “Home” position. There are
several reset functions available on this fixture. The list below details the functionality of
each available selection.
 Reset All: This function will reset all internal motors to the home position.
 Reset Pan and Tilt: This function will only reset the pan and tilt motors to the home
position.
 Reset Colors: This function will only reset the color wheel to the home position.
 Reset Gobos: This function will only reset the gobo wheels to the home position.
 Reset Shutter: This function will only reset the blackout shutter to the home position.
 Reset Others: This function will reset all other motors not associated with any in the
previously listed reset commands to the home position.
