Platinum Spot 5R™
©Elation Professional, Los Angeles Ca. 24 www.ElationLighting.com
9. FIXTURE MENU
On-Board System Menu: The Platinum Spot 5R™ comes with an easy to navigate, full
color system menu. This next section will detail the functions of each command in the
system menu.
LED Control Panel: The control panel located on the base of the fixture allows you to
access the main menu and make all necessary adjustments to the Platinum Spot 5R™.
During normal operation, tapping the “MODE/ESC” key once will access the fixture’s main
menu. Once in the main menu you can navigate through the different functions and access
the sub-menus with the Up and Down buttons. Once you reach a field that requires
adjusting, tap the ENTER button to activate that field and use the UP and Down button to
adjust the field. Tapping the Enter button once more will confirm your setting. Once a setting
is saved the display will briefly readout OK to confirm a new setting has been made and
locked into memory. You may exit the main menu at any time without making any
adjustments by tapping the MODE/ESC button.
MODE/ESC Button - To access the main menu locate the MODE/ESC button on the front
of the unit. Press this button to activate the system menu. Tap the UP button until you reach
the function you wish to change. When you reach the function you wish to change tap the
ENTER button once to select that menu function. When a function is selected, use the UP or
DOWN button to change the function. Once your changes are made tap the ENTER button
yet again to lock the change in the system menu. To exit without making any changes tap
the MODE/ESC button.
The fixture contains a rechargeable battery back-up system that stores all setting and also
allows the menu to be accessed when the fixture is not connected to power. To access the
menu via battery power, press and hold the DC switch button for two seconds, this will
activate the menu. The display will automatically turn off approximately one minute after all
menu commands are completed.
