Platinum Spot 5R™
©Elation Professional, Los Angeles Ca. 35 www.ElationLighting.com
Programs can be created and stored using the fixture’s control board or by using an
external DMX controller. For detailed instructions on how to complete this task please
see Section 12/ Page 39.
9.8.1 Select program – This function allows the user to select one of ten of the user
defined built-in programs. This program is then accessed in “Function Mode” under
“Program Run.”
9.8.2 Edit program – This function allows the user to edit the built-in programs.
9.8.3 Edit Scenes – This function allows the user to edit or define the actual scenes that
are stored in the user defined built-in programs that are accessed in the previous
step.
9.8.4 Rec Controller - The Platinum Spot 5R features an integrated DMX recorder.
Pre-programmed scenes can be transmitted to the fixture via any DMX compliant
controller. This function allows those scenes to be stored in to the fixture’s built-in
memory and then subsequently used to create the user-defined programs.
