1. INTRODUCTION
The Video Distribution Amplifier 0700-006 features four composite and two RGB video inputs, eight
composite and three RGB video outputs, and a briefing active discrete input. The briefing active
discrete input can override the other inputs when activated. The unit is designed to integrate into any
entertainment system that has composite and RGB video capability and controllers that allow you to
select different video sources in the aircraft.
This guide describes general configuration information for the Rosen Video Distribution Amplifier
(VDA) with any video source equipment to supplement the Outline and Installation Drawing.
Note: Only trained and qualified personnel should perform installation and service.
1.1. Unpacking
The following parts are shipped with the Video Distribution Amplifier:
z Outline and Installation Drawing (P/N 0700-006-CD)
z Video Distribution Amplifier (P/N 0700-006)
z Video Distribution Amplifier CD (P/N 101721)
z Connector Kit, 25W3, female (P/N 0300-036)
z Connector Kit, 13W6, female (P/N 0300-703 MOD 00)
z Connector Kit, 8W8, male (P/N 0300-702 MOD 00)
z Connector Kit, 13W6, male (P/N 0300-701 MOD 00)
z Connector Kit w/backshell, 21WA4, female (P/N 0300-034)
The Outline & Installation drawings are also available at
www.rosenaviation.com .
From the Rosen Aviation home page, select Support ÆDrawings and Pinouts, and look for
the product name under the Accessories category.
2. SYSTEM FUNCTIONS
Composite video
input Four composite video sources (A-D) coming into the Video Distribution
Amplifier from video equipment with composite video out.
Composite video
output Individual composite video signals going out of the Video Distribution
Amplifier into 1-8 personal monitors and/or bulkhead monitors.
RGB video input
Two RGB video sources (A & B) coming into the Video Distribution
Amplifier from video equipment with RGB video out.
RGB video output
Individual RGB video outputs going out of the Video Distribution
Amplifier into 1-3 personal monitors and/or bulkhead monitors.
Composite source
select A switch that enables you to select between the available composite
video inputs (four composite video sources A-D are available).
