Rosen Aviation
6.3. Specifications
Table 11 Video Distribution Amplifier specifications
Weight 1.5 lbs [.6804 kg]
Dimensions 9.7” (W) x 1.9” (H) x 4.4” (D)
[246.38 mm (W) x 111.76 mm (H) x 48.26 mm (D)]
Power Requirements 28V DC
Operating Temperature 0ºC - 50ºC
Warranty 2-year
6.4. Troubleshooting
If the video does not function properly, refer to the following troubleshooting tips for symptoms
and possible solutions before contacting Rosen Aviation field support.
Table 12 Troubleshooting tips and solutions
Problem Possible Solutions
Power LED does not
illuminate (GREEN) z Verify that pinout to power input connection is correct.
No video z Wait at least five seconds after turning on the Video
Distribution Amplifier power.
z Verify that the pinout for video is correct.
z Verify video signal on connector pins.
z Verify that video source is in play mode.
z Check for damaged connector pins.
z Check DIP switch configuration.
Amplifier does not cycle
through sources z Check the DIP switch settings and adjust.
z Check for damaged connector pins.
z Verify source select switch operation and pinout.
Differences in picture
brightness z Enable the AGC.
If you need assistance with an installation, please contact Rosen Aviation at 541.342.3802 or
888.668.4955.
7. REVISION HISTORY
Revision Date Revision Description EC #
A 10/14/08 Initial release 08300
Document Number: 101720 Revision: A
Date: 10/14/08
