Model PD6060 Dual-Input Process Meter Instruction Manual
96
Display Parameter Action/Setting Description
diamr Diameter
Enter the tank’s diameter in inches or cm
d-Inty
Display
intensity
Set display intensity level from 1 to 8
Dis 1
Display 1
Program display 1 value
Dis 2
Display 2
Program display 2 value (up to 32 points)
disabl Disable
Disable function key
DLY 1 Delay 1
Enter relay 1 time delay setup (1-8)
Do 1
Digital output 1
Assign digital output 1 – 8, if expansion
modules are connected
done
Done
Copy function completed
Dset 1
Display set 1
Select to display set point 1 (1-8)
dsplay Display
Enter the Display menu
Enter
Enter button
Assign digital input to Enter button/F3
Error
Error
Error, calibration not successful, check signal
or programmed value
F On 1
Force On 1
Force relay 1 on using and digital input
F1
F1 function key
Assign F1 function key
F2 F2 function key
Assign F2 function key
F3
F3 function key
Assign F3 function key
F4
F4 function key
Assign F4 function key (digital input)
Factor Factor
The channel C math function multiplication
factor constant F
FaiLSF Fail-safe
Enter Fail-safe menu
filter Filter
Set noise filter value
FLS 1
Fail-safe 1
Set relay 1 fail-safe operation (1-8)
Force
Force
Force analog output value for loop break
Functn Signal input
conditioner
Select linear, square root, programmable
exponent, or round horizontal tank function
ICal Internal
calibration
Enter internal calibration (used for
recalibrating the meter with a calibrated
signal source)
ignore
Ignore
Ignore loop break condition
Inch
Inch
Select inch as the tank unit of measurement
Info
Information
Display software and S/N information
Inp 1
Input 1
Calibrate input 1 signal or program input 1
value
Inp 2
Input 2
Calibrate input 2 signal or program input 2
value (up to 32 points)
input
Input
Enter Input selection menu
LatCH
Latching
Set relay for latching operation
LED t LED test
Test all LEDs
Length Length
Enter the tank’s length in inches or cm
Linear
Linear
Set meter for linear function and select
number of linearization points
Lit HC
Max on little
Assign digital input to display max of
