A-5 CrossPoint Matrix Switchers • Specifications
Cables
When using signals with a scanning frequency of 15-125 kHz and running distances
of 100 feet or more, use high resolution BNC cables to achieve maximum
performance.
Bulk cable
Extron Part Part #
RG6 super high resolution cable
Bulk RG6-1, 500’
22-098-02
Bulk RG6-1, 1000’ 22-098-03
Bulk RG6-4, 500’ 22-099-02
Bulk RG6-5, 500’ 22-100-02
RG6 male crimp connectors, qty. 50 100-075-51
BNC-4 Mini HR Cable
Bulk BNC 4-500’ HR
22-032-02
Bulk BNC 4-1000’ HR 22-032-03
BNC-5 Mini HR Cable
Bulk BNC 5-500’ HR
22-020-02
Bulk BNC 5-1000’ HR 22-020-03
Plenum BNC-5 Mini HR Cable
Bulk BNC 5-500’ HRP
22-103-02
Bulk BNC 5-1000’ HRP 22-103-03
Assorted connectors
BNC connectors
BNC Mini HR crimp connectors, qty. 50
100-074-51
RG6 male crimp connectors, qty. 50 100-075-51
BNC bulkhead connectors, qty. 50
(for custom wall plates) 100-076-51
Pre-cut cables
BNC-4 Mini HR cable is used for RGBS cable runs, and BNC-5 Mini HR cable is
used for RGBHV cable runs. Either type can also be used for composite video,
S-video, or RGsB. All Extron BNC cables have male connectors on both ends. A
plenum version of the BNC-5 Mini HR cable is also available.
BNC-4 Mini HR Cable
BNC-4-25’ MHR (25 feet/7.5 meters)
26-210-04
BNC-4-50’ MHR (50 feet/15.0 meters) 26-210-05
BNC-4-75’ MHR (75 feet/23.0 meters) 26-210-06
BNC-4-100’ MHR (100 feet/30.0 meters) 26-210-07
BNC-4-150’ MHR (150 feet/45.0 meters) 26-210-08
BNC-4-200’ MHR (200 feet/60.0 meters) 26-210-09
BNC-4-250’ MHR (250 feet/75.0 meters) 26-210-54
BNC-4-300’ MHR (300 feet/90.0 meters) 26-210-53
