Programmer’s Guide, cont’d
CrossPoint Matrix Switchers • Programmer’s Guide 4-4
Command/Response Table
Symbol Definitions:
= Carriage return/line feed
= Carriage return (no line feed)
• = Space
X1
= Input number 01 – 08 (CrossPoint 84, 88);
01 – 12 (CrossPoint 124, 128);
01 – 16 (CrossPoint 168, 1616)
X2
= Output number 01 – 04 (CrossPoint 84, 124);
01 – 08 (CrossPoint 88, 128, 168);
01 – 16 (CrossPoint 1616)
X3
= Input number (for tie) 0 – maximum number of inputs (0=disconnected)
X4
= Audio gain 0 – 9 (1dB/step)
X5
= Audio attenuation 1 – 15 (1dB/step)
X6
= Numeric dB value -15 to +09
X7 = Preset number 00 – 16 (0 = current configuration)
X8 = Preset number 01 – 16
X9
= Mute status 0 = no mute, 1 = video mute, 2 = audio mute, 3 = V and A mute
X10
= Executive mode, mute 1 = on;
0 = off
X11
= Controller software version number to second decimal place
Command/response table for SIS commands
Command ASCII Command Response Additional description
(host to switcher) (switcher to host)
Create ties
Tie input X3 to output X2 , A & V X3 * X2 ! Out X2 •In X3 •All
Example: 1*3! Out03•In01•All Tie input 1 A & V to output 3.
Tie input to output, RGBHV only X3 * X2 & Out X2 •In X3 •RGB Audio breakaway.
Example 1 : 10*4& Out04•In10•RGB Tie input 10 RGB to output 4.
Tie input X3 to output X2 , video only X3 * X2 % Out X2 •In X3 •Vid Audio breakaway.
Example 1 : 7*5% Out05•In07•Vid Tie input 7 video to output 5.
Tie input X3 to output X2 , audio only X3 * X2 $ Out X2 •In X3 •Aud Audio breakaway.
Example: 12*8$ Out08•In12•Aud Tie input 12 audio to output 8.
Quick multiple tie Esc Q X3 * X2 !… X3 * X2 ! Out•Multi•In•Multi•All
Example: Esc Q3*4!3*5!3*6! Out•Multi•In•Multi•All Tie input 3 to outputs 4, 5, and 6.
Tie input to all outputs
X3
! Out•Multi•In X3 •All
Example: 5! Out•Multi In05•All Tie input 5 to all outputs.
Audio input gain and attenuation
Set audio input gain to +dB value X1 * X4 G In X1 •Aud= X6
Example: 1*2G In01•Aud=+02 Set input 1 audio gain to +2dB.
Set audio input attenuation to -dB value X1 * X5 g In X1 •Aud= X6
Increment gain up X1 {G In X1 •Aud= X6
Example: 5 {G In05•Aud=+03 Audio input 5 level incremented
from +2dB to +3dB.
Decrement gain down X1 }G In X1 •Aud= X6
Example: 7 }G In07•Aud=-09 Audio input 7 level decremented
from -8dB to -9dB.
1 The & tie command for RGB and the % tie command for video can be used interchangeably on the CrossPoint models.
Input and output numbers in
commands may be entered as
either 1-digit or 2-digit numbers.
All input and output numbers
are specified as 2-digit numbers
in the response.
